The Horger range of athletic track and artificial turf cleaning equipment is specifically developed for high pressure cleaning with extraction of dirty water in one stage for assembly with compact and narrow gauge tractors. The athletic track cleaner consists of a cleaning unit which is assembled at the front of the tractor and a tank pumpunit for rear assembly. The rear tank is divided into a fresh water container and a dirty water container. The fresh water is sucked in by a high pressure pump, which is driven by a drive shaft, and carried via hoses to the front cleaning unit. Demands on the carrier vehicle: Front and rear lift equipment with drive shaft, max. outside width up to 1.45 metres, suitable tyres, slowest driving speed about 0.4 km/h with full-open-throttle. (Vehicles with a greater outside width on demand) Front cleaning unit: Work width 150 cm, 2 nozzle rotors, edge strip nozzle, dirty water pump, extract ventilating fan, separating tank, cardan shaft. Tank pump unit for rear assembly. Double box tank for fresh and dirty water, steering axle with pneumatic tyres, fittings, pressure hoses, cardan shaft, dirty water tap, brackets. Version each 600 l volume; Version each 1000 l volume, from 2000 kg tractor dead weight Pump tooling: As per capacity of the drive shaft of the tractor
Artificial turf is influenced by the environment from the first day on. Dust, pollen, plant residue and abrasion material are washed by rain into the fine cavities of the filling. The result of this process is a total hardened surface with less water permeability. The covering infiltrated with particles of humus and other debris is the ideal breeding ground for algae and moss. There are three different processes that can be done with this machine due to its brush diameter of 500 mm. 1. Maintenance cleaning: Depending on weather every two to four weeks. Coarse soiling and accumulated dust as well as abrasion is removed. 2. Intensive cleaning with loosening: About every 3 months. Coarse soiling is removed, fine particles like dust, plant rests and abrasion is filtered, filling is loosened, elasticity and drainage effect is maintained. 3. Reactivation of a surface untreated for several years: The hardenings are broken up, most of the filling is taken up, loosened, led back and extensively brought back into the turf pile. Coarse soiling is removed, fine particles, responsible for hardenings, are filtered. The hardened filling is loosened, the artificial turf is loose and flexible again, accident risk decreases and drainage effect is repaired.
For intensive cleaning and extraction of dirty water in one single operation, developed for compact and small tractors. The artificial turf cleaner consists of a cleaning attachment in the front mounted pump and a tank unit in the rear mounting. The rear tank is divided into a fresh and a waste area. The high pressure pump powered by the PTO shaft sucks the fresh water and forces it through hoses to the front cleaning purpose. Here, the cleaning is done in the alluvial brush system with pure water without added detergents. The dirty water in the rear recovery tank will be transported and extracted with an injector pump. Even moss and algae is removed by using our artificial turf cleaner SKR. Furthermore, the tank-and-pump unit is compatible with our synthetic track cleaner KBR front cleaning purpose. Frontal cleaning attachment: Working width 1.50 m, with 500 mm diameter cylindrical brush, nozzle manifold, dirt water pump, drive shaft, pick-up attachment removable for mounting coarse dirt attachment. Tank pump unit for rear assembly: Double box tank for fresh and dirty water, steering axle with pneumatic tyres, fittings, pressure hoses, cardan shaft, dirty water tap, brackets. from 2000 kg tractor dead weight. Pump tolling: As per capacity of the drive shaft of the tractor
